Description

473 nm, 532 nm and 589 nm Combined YGB DPSS Laser System

The LMS-YGB2 Series of Combined-wavelength Diode-Pumped Solid-State (DPSS) Lasers are ideal for applications requiring yellow, green, and blue wavelengths to be emitted from a single laser module. These BGY laser systems are available with >300 mW combined output power with a high level of long-term output power stability and long operating lifetime, all at an aggressively competitive cost.

These lasers are commonly used for laser light shows (entertainment) as well as scientific applications including PIV, Raman Spectroscopy, and others. The driver is available as a complete FDA-compliant system or as an O.E.M. component with significantly reduced dimensions.

Available with TTL and Analog modulation, and in a wide array of output power and stability levels, Laserglow products are currently being used by some of the World's top universities and other prominent research facilities.

Key Features:

• Air cooled - no need for water cooling or external chiller
• Lightweight, compact design
• Efficient DPSS technology runs on standard AC power (85 - 264 V, 47 - 63 Hz)
• >10,000 hours continuous maintenance-free operating life
• TTL and Analog modulation (input via BNC connector) lab-spec models only
• Adjustable output power via lockable dial) lab-spec models only
• LED display showing LD current, laser cavity temperature lab-spec models only
• FDA CDRH Compliant Class IIIb / Class IV enclosure
• 48-hour replacement coverage available for an additional fee on specific models

• Laser Head
• Driver/Power Supply
• Power Cable
• BNC Connector (LabSpec models only)
• Keys, Safety Interlock
• Hard-shell Carrying Case
